SFSP668系列水滴型宽式细粉碎机

    • SFSP668系列水滴型宽式细粉碎机
    • SFSP668系列水滴型宽式细粉碎机
    • SFSP668系列水滴型宽式细粉碎机
    • SFSP668系列水滴型宽式细粉碎机
    • SFSP668系列水滴型宽式细粉碎机
    • SFSP668系列水滴型宽式细粉碎机
产品详情

产品特点

1、宽式微细粉碎机被大、中型畜禽和水产饲料企业用于粉碎原料;同时也适用于牧草粉碎和制药行业的细微粉碎。可粉碎各种颗粒状饲料原料,如玉米、高梁、麦类、豆类、破碎后的饼粕以及其他物料;
2、作为水滴型粉碎机的派生系列,与普通粉碎机相比,效率提高45%-90%,是普通锤片粉碎机的替代机型;
3、装配¢0.8、¢1毫米筛网条件下该机能满负荷生产出精细的水产料并大大改善堵塞现象;不需换筛就可以实现粗、细两种粉碎;
4、通风合适能使物料穿过筛孔速度加快,粉碎室温度降低,物料温度较低,有效提高产量。

主要技术及性能参数

参 数

型 号

转子直径(mm)

粉碎室宽度(mm)

主轴转速(r/min)

锤片线速(m/s)

锤片
数量(pc)

配用动力(kw)

正常吸风量(m³/min)

产量(t/h)

一般粉碎

细粉碎

SFSP668-Ⅰ

660

380

2970

94

56

22/30

30

34

5-6

SFSP668-Ⅱ

660

450

2970

94

64

45/55

40

45

7-12

SFSP668-Ⅲ

660

600

2970

94

88

55/75

48

53

10-15

SFSP668-Ⅳ

660

750

2970

94

112

90/110

60

66

15-20

注:以上指标是满足以下情况时的指标:原料为玉米、水份不大于14%,容量不低于0.72t/m3,粉碎机筛板直径为¢3mm,开孔率不低于33%。

Features:

1. It is used for grinding raw materials of large and medium livestock and aqua feed mills. It can also be used for grass and pharmacy fine grinding. The granular raw materials, such as corn, sorghum, wheat, beans, etc can be ground;
2. It is derived from the tear circle type hammer mill and efficiency can be improved by 45%-90% compared to universal hammer mill;
3. It can produce qualified aqua feed under full load with ¢0.8、¢1 screen and reduce jam significantly. Both coarse and fine grinding can be completed without changing screens;
4. The right aspiration can make materials go through screen quickly, reduce temperature of grinding chamber and increase output effectively.

Main Technical Parameters:

Parameters

Model

Dia. Of Rotor

(mm)

Width Of Grinding Chamber (mm)

Speed Of Rotor (r/min)

Speed Of Beater (m/s)

No. Of Beater (pc)

Power (kw)

Aspiration (m³/min)

Output(t/h)

Coarse

Fine

SFSP668-Ⅰ

660

380

2970

94

56

22/30

30

34

5-6

SFSP668-Ⅱ

660

450

2970

94

64

45/55

40

45

7-12

SFSP668-Ⅲ

660

600

2970

94

88

55/75

48

53

10-15

SFSP668-Ⅳ

660

750

2970

94

112

90/110

60

66

15-20

Re: The above indexes are those when meeting the following conditions: raw material: corn, moisture content not higher than 14%, density not lower than 0.72t/m3, screen: hole diameter ¢3mm, hole-opening rate not less than 33%.
