SHGF系列浮动式干燥机

    • SHGF系列浮动式干燥机
    • SHGF系列浮动式干燥机
产品详情

产品特点

1、烘干过程中物料颗粒个体在风板上呈悬浮并自旋状态,物料整体处于流化状态,与热空气混合、接触,进行热交换。均匀受热后的物料在刮板带动下运动,运动时间可调。因此,浮动式干燥机可根据用户生产的需要,烘干不同颗粒直径的膨化料;

2、先进的干燥原理,使单台设备产量得到大幅度的提高;

3、干燥时间可调,保证物料干燥效果好;

4、采用双层烘干结构,热空气从底部从下而上穿透两层料层,从而提高了热能的利用率,降低了使用成本;

5、散热片直接置于干燥机底部,减少了设备占地面积;

6、适用于膨化饲料的烘干。

主要技术及性能参数

参数

型号

处理量(t/h)

失水率(%)

功率(kw)

外形尺寸(l×m×h mm)

SHGF120×2

1-2

≤15

2.6

6570×1900×3580

SHGF180×2

2-3

≤15

2.6

7770×2500×3680

SHGF Series Floating Dryer

SHGF系列浮动式干燥机

Features

1. Double-scratch boards convey the materials.

2. Flowing and drying are integrated. It makes the material float in the machine.

3. It ensures the mill not distorting and can adjust the drying time.

4. It is small area occupied.

5. Capable of drying extruded feed.

6. The power is double-floor steam cooling fin.

Main Technical Parameters

Parameters

Model

Capacity/Batch

(t/h)

Moisture Loss

(%)

Power

(kw)

Floor Area

(l × w × h mm)

SHGF120×2

1-2

≤15

2.6

6570×1900×3580

SHGF180×2

2-3

≤15

2.6

7770×2500×3680
